来源：gounbot 2019年11月06日 08:59
finex 侧杯喷枪带有一个旋转的杯子
– 非常适合终端用户在狭窄空间内使用。 提供hvlp 或常规技术。
功能：
1.铝杯位于喷枪中
2.杯转环用于在小空间内喷涂
3.很轻的扳机引力让操作员更舒适
4.喷嘴经过优化，可实现高质量的喷涂效果
5.一体式风门调节（加长管钳把的管子）阀
规格：
| finex gravity feed airspray guns | |
| maximum air inlet pressure | 7.0 bar, 0.7 mpa |
| maximum fluid working pressure | 7.0 bar, 0.7 mpa |
| maximum hvlp inbound air pressure | 2.0 bar, 0.2 mpa |
| fluid and air operating temperature range | 0–43°c |
| air inlet | 1/4 npsm (r1/4–19) |
| wetted parts | aluminum, stainless steel, engineered plastic |
| gravity cup size | |
| mini hvlp gravity feed spray guns | 125 cc |
| standard conventional and hvlp gravity feed spray guns | 600 cc |
| weight | |
| mini hvlp gravity feed gun, with cup | 0.4 kg |
| standard gravity feed gun, with cup | 0.5 kg |
| air consumption | |
| mini hvlp gravity feed spray guns at 29 psi (2.0 bar, 0.2 mpa) | 0.20 m³/min |
| conventional gravity feed spray guns at 43 psi (3.0 bar, 0.3 mpa) | 0.27 m³/min |
| hvlp gravity feed spray guns at 29 psi (2.0 bar, 0.2 mpa) | 0.27 m³/min |
| noise data | |
| mini hvlp gravity feed spray guns | |
| sound power at 29 psi (2.0 bar, 0.2 mpa) | 85.32 db(a) |
| sound pressure at 29 psi (2.0 bar, 0.2 mpa) | 78.17 db(a) |
| conventional gravity feed spray guns | |
| sound power at 43 psi (3.0 bar, 0.3 mpa) | 89.23 db(a) |
| sound pressure at 43 psi (3.0 bar, 0.3 mpa) | 81.91 db(a) |
| hvlp gravity feed spray guns | |
| sound power at 29 psi (2.0 bar, 0.2 mpa) | 87.74 db(a) |
| sound pressure at 29 psi (2.0 bar, 0.2 mpa) | 80.60 db(a) |
