graco invisipac hm25c
适用于紧凑型kok体育娱乐官网的解决方案的全新设计
invisipac hm25c
无胶缸式热熔胶输送系统采用紧凑型设计，在任何包装生产线上均可方便安装。此外，由于控制都已集成在内置电路板中，因此，该设备可不依赖其控制面板 (adm) 而独立工作。 这意味着，各项控制可在远端进行操作或集成于其他控制面板中。
优势：
- 10 分钟启动时间
- 8 通道连接
- 标准集成式材料跟踪
- 自动关闭功能，达到用户定义的空转时间后将自动关闭
- 通过 usb 下载工作数据、错误和事件历史记录
- 对设备性能进行定量分析，改进预防性维护，减少停机时间
- 内部模式控制，可对大多数配置轻松进行模式设置
- 随着条件的改变，自动调节注入量功能可随时间进行调节，无需进行校准
- 熔胶速度为 11.3 kg/h (25lb/h)。
跟踪热熔胶用量
清楚了解产线的配置是达到工艺的关键。因此，固瑞克的每一款 invisipac 热熔胶系统都将材料跟踪功能作为标配。借助材料跟踪功能，您将能够：
- 跟踪材料用量和其他生产事件
- 以图表形式呈现热熔胶消耗情况，让您轻松跟踪每台设备的成本，从而节约成本并保证质量
- 当材料用量超出预期范围时，将收到警报和生产线的相关性能通知。
- 快速启动 —— 启动预热在 10 分钟之内完成
- 无胶缸，避免因碳化造成喷嘴堵塞
- 粘合剂粘度保持稳定
- 材料性能保持稳定
- 可靠稳定的密封效果
- 几乎无浪费
- 更好的分配控制
- 提升操作员的安全性
- 可使用您选择的任何粘合剂
- 性能强大，组件耐用
规格：
| invisipac hot melt delivery system | |
| incoming power | |
| 24t918 |
200-240 vac, 1-ph, 50/60 hz, 32a, 200-240 vac, 3-ph, δ, 50/60 hz, 27a, 350-415 vac, 3-ph, y, 50/60 hz, 16a
|
| 24v429, 24v201 |
400-480 vac, 3-ph, δ, 50/60 hz, 14a
|
| 24t919 |
200-240 vac, 1-ph, 50/60 hz, 40a, 200-240 vac, 3-ph, δ, 50/60 hz, 27a, 350-415 vac, 3-ph, y, 50/60 hz, 16a
|
| 24v430, 24v202 |
400-480 vac, 3-ph, δ, 50/60 hz, 14a
|
| 24t920 |
200-240 vac, 1-ph, 50/60 hz, 40a200-240 vac, 3-ph, δ, 50/60 hz, 40a350-415 vac, 3-ph, y, 50/60 hz, 30a
|
| 24v431, 24v203 |
400-480 vac, 3-ph, δ, 50/60 hz, 14a
|
| electrical | |
| maximum applicator wattage per channel |
400 w
|
| input / output capability |
4 inputs (0-30v), 4 outputs (240vac, 24vdc, 2a)
|
| pump flow rate | |
| hm25 |
43.5 kg/hr
|
| hm50 |
59 kg/hr
|
| melt rate / constant throughput | |
| hm25 |
11.3 kg/hr
|
| hm50 |
22.6 kg/hr
|
| weight | |
| hm25 |
36 kg
|
| hm50 |
48 kg
|
| general | |
| adhesive |
1/4 in. (6 mm), round, adhesive pellets
|
| pump output |
17.2 cc/cycle
|
| time to temperature, (from 70°f to 350°f (21°c to 177°c), dependant upon power supply and machine configuration.) |
less than 15 minutes
|
| pump |
pneumatic piston, 12:1
|
| channels |
1 to 6
|
| system dimensions, without vacuum tube or shaker (width x height x depth), (excludes vacuum transfer tube, shaker assembly, and pellet storage bin) |
483 x 1067 x 419 mm
|
| shaker dimensions (width x height) |
0.12 x 1.22 m
|
| pressure and temperature ranges | |
| main system air supply pressure range (set with regulator on front of system) |
0.55-0.69 mpa (5.5-7 bar)
|
| pump operating air pressure range |
0.14-0.69 mpa (0.7-7 bar)
|
| pump operating fluid pressure range |
1.7-8 mpa (17-80 bar)
|
| control temperature range |
38-204°c
|
| ambient temperature range |
38-204°c
|
| vacuum transfer specifications | |
| maximum vacuum transfer hose length |
9.1 m
|
| maximum vacuum transfer hose maximum vertical rise |
3.0 m
|
| vacuum transfer operating pneumatic pressure range (set with regulator on front of system) |
280-690 kpa (2.8-6.9 bar)
|
| vacuum transfer air consumption at 40 psi (280 kpa, 2.8 bar) |
16.1 scmh (intermittent duty; 4% at 11.3 kg/hr)
|
| vacuum transfer air consumption at 80 psi (550 kpa, 5.5 bar) |
29.2 scmh (intermittent duty; 4% at 11.3 kg/hr)
|
| required air tubing size | |
| minimum air tubing inner diameter (less than 50 ft, 15.2 m of tubing) |
9.5 mm
|
| minimum air tubing inner diameter (50 ft, 15.2 m or longer of tubing) |
12.7 mm
|
| sound | |
| sound pressure level, pressure level measured 3.1 ft (1 meter) from equipment |
77 db(a)
|
| ip code | |
| invisipac base system |
ip54
|
| wetted parts | |
| wetted parts |
ptfe, chemically resistant o-rings, aluminum, stainless steel, zinc plating, carbon steel, brass, carbide, chrome
|
| approvals and standards |
ul499, csa88, ce, iso
|
| 30 gallon vibrating hopper | |
| required air pressure supplied to 30 gallon vibrating hopper |
0.7 mpa (7 bar)
|
| air consumption |
29.1 cubic meters per hour
|
