gounbot-ad10as precision dispensing controller

gounbot-ad10as precision dispensing controller

parameter description


one: panel instructions


1 ... .. operation panel

2 ... .. pressure regulating valve

3 ... pressure display

4 ... .. suction control button

5 ... .. pressure outlet (needle head adapter)

6 ... .. air pressure input port

7 ... .. foot switch signal connection port

8 ... .. power switch

9 ... .. power input (24vdc)

ii: description of the operation panel buttons

first, the light shows

1.dispense ....... spit glue display light

2.teach ......... ... set the exit time for the elapse time / interval

3. manual ... ... manual mode

4.timer ............ time mode

5.cycle ............ cycle mode

6. program ... ... program group mode

second, the model description

1. manual mode (manual): press the shot, direct timing spit gum.

2. time mode (timer):

a. press the set key, with the digital increase / decrease / left to set the time to spit.

b. press the teach button, teach light flashes, then press the shot key to teach spit gum time, exit key to cancel.

c. press the shot key, according to spit gum time to spit gum, spit gum time.

3. cycle mode:

a. press the set key, with the digital increase / decrease / left shift, you can set the interval time.

b. press the teach button, teach light flashes, then press the shot key to teach the interval time, exit key to cancel.

c. press the shot key, according to the time to spit plastic spit, according to the time interval to stop spit gum, spit the infinite number of times, and then

press the shot key once to stop the loop.

4. program group mode (program):

a. press the set key to set the program group, 00-39 group, 40 groups.
