finex 侧杯喷枪带有一个旋转的杯子 – 非常适合终端用户在狭窄空间内使用。 提供hvlp 或常规技术。

功能：

1.铝杯位于喷枪中
2.杯转环用于在小空间内喷涂
3.很轻的扳机引力让操作员更舒适
4.喷嘴经过优化，可实现高质量的喷涂效果
5.一体式风门调节（加长管钳把的管子）阀

规格：

finex gravity feed airspray guns
maximum air inlet pressure	7.0 bar, 0.7 mpa
maximum fluid working pressure	7.0 bar, 0.7 mpa
maximum hvlp inbound air pressure	2.0 bar, 0.2 mpa
fluid and air operating temperature range	0–43°c
air inlet	1/4 npsm (r1/4–19)
wetted parts	aluminum, stainless steel, engineered plastic
gravity cup size
mini hvlp gravity feed spray guns	125 cc
standard conventional and hvlp gravity feed spray guns	600 cc
weight
mini hvlp gravity feed gun, with cup	0.4 kg
standard gravity feed gun, with cup	0.5 kg
air consumption
mini hvlp gravity feed spray guns at 29 psi (2.0 bar, 0.2 mpa)	0.20 m³/min
conventional gravity feed spray guns at 43 psi (3.0 bar, 0.3 mpa)	0.27 m³/min
hvlp gravity feed spray guns at 29 psi (2.0 bar, 0.2 mpa)	0.27 m³/min
noise data
mini hvlp gravity feed spray guns
sound power at 29 psi (2.0 bar, 0.2 mpa)	85.32 db(a)
sound pressure at 29 psi (2.0 bar, 0.2 mpa)	78.17 db(a)
conventional gravity feed spray guns
sound power at 43 psi (3.0 bar, 0.3 mpa)	89.23 db(a)
sound pressure at 43 psi (3.0 bar, 0.3 mpa)	81.91 db(a)
hvlp gravity feed spray guns
sound power at 29 psi (2.0 bar, 0.2 mpa)	87.74 db(a)
sound pressure at 29 psi (2.0 bar, 0.2 mpa)	80.60 db(a)
